UV Coating and UV Wrapping - Technology Study on Coating and Wrapping Technologies for Battery Cells

Situation und Motivation

When producing battery packs, it's crucial to apply an insulating layer for prismatic cell formats. Two main technologies are used for large-scale production: coating and wrapping the battery cell package. However, coating technology can have inaccuracies, particularly in the edge areas or for slightly convex or concave cell packages. This study investigated a UV wrapping with epoxy technology that could eliminate these issues.

Project description

The study focused on applying UV coating and UV wrapping with epoxy technology to create an insulating layer for battery cell housing before integrating it into a battery pack.

To begin, we needed to establish specific requirements for both the cell and its coating. We established evaluation criteria to compare the two technologies. The coating technology had slightly lower costs, while the UV wrapping with epoxy had advantages in processing time and quality. We evaluated both technologies based on time, cost, quality, sustainability, and process control. We found that pre-treatment with a laser was only necessary for UV coating technology, which gave UV wrapping with epoxy an advantage. The subsequent cleaning step was required for both technologies. UV wrapping with epoxy had advantages in the coating process and drying step, as multiple coats of paint were not required. It also had a more uniform coating thickness at the edge areas, making the end-of-line test and post-processing easier. UV wrapping with epoxy technology was successful in all process steps and we will continue to examine the products further.

Results

  • When UV-curing materials are used, the temperature required for curing can be lowered to 20°C. This protects the cell from unnecessary aging processes.
  • Curing takes place within a few seconds.
  • The UV coating process is characterized by increased robustness due to fewer moving machine parts.
  • By using UV Epoxy Tape, higher flexibility in the process and higher accuracy can be achieved.
  • Based on the process step analysis, some advantages of UV Wrapping with Epoxy Technology compared to UV Coating could be identified
